Further Information
The Eventuri F3 RSQ3 intake system delivers exceptional flow rates while maintaining minimal intake temperatures. Originally developed for high-power RS3 builds, this system features a patented Venturi housing design that provides a smooth, free-flowing path from the filter to the turbo inlet. The sealed design incorporates an innovative duct that draws cold air from behind the hood, equivalent to an extra 7" diameter opening.
Engineered with precision-matched 103mm internal diameter components and a bespoke 210mm diameter filter with over 130,000mm² filtration surface area, this intake achieves 840 CFM flow while keeping temperatures at a minimum. The entire system is constructed from 100% pre-preg carbon fiber with no fiberglass, ensuring smooth internal surfaces and superior heat insulation.
Key Features:
- Patented carbon fiber Venturi filter housing provides maximum internal volume with laminar flow characteristics
- Bespoke high-flow dry cone filter sized at 210mm outer diameter with 130,000mm² filtration surface
- 103mm internal diameter intake tube with smooth curvature minimizes pressure drop and maintains laminar conditions
- Sealed system design with hood-fed duct opening prevents heat soak and intake air temperature rise
- 100% pre-preg carbon fiber construction with smooth internal surfaces versus restrictive fiberglass alternatives
- Gold reflective heat shield protects carbon tube from turbo and catalyst radiation and convective heat
- Compatible with larger aftermarket throttle bodies and supports hybrid and full-frame turbo setups
Performance Notes:
- +15-18hp and 19-23ft-lb on RS3 with stock turbo
- +25-30hp and 20-24ft-lb on RS3 with hybrid turbo
- 840 CFM flow rate versus 530 CFM stock intake—58% improvement
- Proven support for 1010whp builds on full-frame turbo applications
- Lower boost requirements compared to alternative intake systems
Includes:
- Carbon fiber patented Venturi filter housing with 103mm outlet
- Bespoke high-flow dry cone filter
- Carbon fiber inlet duct with sealed design
- Carbon fiber intake tube with 103mm internal diameter
- Heat shield with gold reflective backing
- Laser-cut stainless steel brackets
- Silicon breather hose, couplers, and reducer
- Installation hardware and guide
Maximum flow. Minimum heat. Stage 3 performance for the RSQ3.
| Manufacturer | Model | Years | Generations | Variant | Engine Code(s) |
|---|---|---|---|---|---|
| Audi | RSQ3 | 2019 | RSQ3 Sportback | RSQ3 Sportback-2.5 TFSI (400 Hp) quattro S tronic | EA855evo/DNWA |
| Audi | RSQ3 | 2019 | RSQ3 (F3) | RSQ3 (F3)-2.5 TFSI (400 Hp) quattro S tronic | EA855evo/DNWA |
