Further Information
The Eventuri RS3/TTRS Turbo Inlet is a world-first all-carbon turbo inlet elbow engineered for maximum flow, optimal flow quality, and minimal heat transfer. Manufactured from high-temperature prepreg carbon fiber with precision CNC machined components, this inlet replaces the restrictive stock elbow with a de-restricted flow path that significantly improves turbo response and engine performance across the RS3 8V Gen 2, 8Y, and TTRS 8S platforms.
Key Features:
- High-temperature prepreg carbon fiber construction with 2mm wall thickness throughout
- Inlet diameter increased to 103mm (stock: 72mm) and outlet to 74mm (stock: 56.4mm) for superior flow capacity
- Smooth internal carbon surface minimizes turbulence compared to cast aluminum alternatives
- Silicon coupler with integrated thermal spacer isolates carbon elbow from turbo heat conduction
- Heat reflective layer protects tube where it crosses exhaust manifold
- Raw carbon finish (no clearcoat) withstands extreme turbo and exhaust heat
- Available in RHD and LHD configurations with RHD scallop design for brake fluid reservoir clearance
- Optional CNC machined turbo flanges for stock, TTE700/625, and SRM GTX turbos
Performance Notes:
- 14-20hp gain on RS3 with hybrid turbo
- 30-35ft-lb torque increase
- 42% flow rate increase at 24″ H2O using stock flange
- Up to 58% maximum flow improvement using GTX flange
- 52% flow increase on RHD version despite brake reservoir scallop
- Independent dyno testing shows +14.3hp over stock inlet on TTE700 equipped TTRS
Includes:
- High-temperature carbon inlet elbow (RHD or LHD specific)
- CNC machined aluminum turbo flange options
- Silicon couplers with oil-resistant lining
- Marine-grade stainless steel hose clamps
- Installation hardware and guide
Maximum flow. Minimum heat. Maximum power. The Eventuri difference.
| Manufacturer | Model | Years | Generations | Variant | Engine Code(s) |
|---|---|---|---|---|---|
| Audi | RS3 | 2015, 2016 | RS3 sportback (8VA) | RS3 sportback (8VA)-2.5 TFSI (367 Hp) quattro S tronic | CZGB |
| Audi | RS3 | 2024 | RS3 Sportback (8Y, facelift 2024) | RS3 Sportback (8Y, facelift 2024)-2.5 TFSI (400 Hp) quattro S tronic | |
| Audi | RS3 | 2024 | RS3 Sedan (8Y, facelift 2024) | RS3 Sedan (8Y, facelift 2024)-2.5 TFSI (400 Hp) quattro S tronic | |
| Audi | RS3 | 2021, 2022, 2023, 2024 | RS3 Sportback (8Y) | RS3 Sportback (8Y)-2.5 TFSI (400 Hp) quattro S tronic | EA855evo/DNWC |
| Audi | RS3 | 2021, 2022, 2023, 2024 | RS3 Sedan (8Y) | RS3 Sedan (8Y)-2.5 TFSI (400 Hp) quattro S tronic | EA855evo/DNWC |
| Audi | RS3 | 2017, 2018, 2019, 2020 | RS3 sportback (8VA, facelift 2017) | RS3 sportback (8VA, facelift 2017)-2.5 TFSI (400 Hp) quattro S tronic | EA855evo/DAZA |
| Audi | RS3 | 2017, 2018, 2019, 2020 | RS3 sedan (8V, facelift 2017) | RS3 sedan (8V, facelift 2017)-2.5 TFSI (400 Hp) quattro S tronic | EA855evo/DAZA |
| Audi | TT | 2021, 2022 | TT RS Coupe (8S, facelift 2019) | TT RS Coupe (8S, facelift 2019)-Heritage Edition 2.5 TFSI (394 Hp) quattro S tronic | EA855evo/DAZA |
| Audi | TT | 2020, 2021, 2022, 2023 | TT RS Coupe (8S, facelift 2019) | TT RS Coupe (8S, facelift 2019)-2.5 TFSI (400 Hp) quattro S tronic | EA855evo/DNWA |
| Audi | TT | 2019, 2020 | TT RS Roadster (8S, facelift 2019) | TT RS Roadster (8S, facelift 2019)-2.5 TFSI (400 Hp) quattro S tronic | EA855evo/DAZA |
| Audi | TT | 2020, 2021, 2022, 2023 | TT RS Roadster (8S, facelift 2019) | TT RS Roadster (8S, facelift 2019)-2.5 TFSI (400 Hp) quattro S tronic | EA855evo/DNWA |
| Audi | TT | 2019, 2020 | TT RS Coupe (8S, facelift 2019) | TT RS Coupe (8S, facelift 2019)-2.5 TFSI (400 Hp) quattro S tronic | EA855evo/DAZA |
| Audi | TT | 2016, 2017, 2018 | TT RS Roadster (8S) | TT RS Roadster (8S)-2.5 TFSI (400 Hp) quattro S tronic | EA855evo/DAZA |
| Audi | TT | 2016, 2017, 2018 | TT RS Coupe (8S) | TT RS Coupe (8S)-2.5 TFSI (400 Hp) quattro S tronic | EA855evo/DAZA |
| Audi | RSQ3 | 2019 | RSQ3 (F3) | RSQ3 (F3)-2.5 TFSI (400 Hp) quattro S tronic | EA855evo/DNWA |
| Audi | RSQ3 | 2019 | RSQ3 Sportback | RSQ3 Sportback-2.5 TFSI (400 Hp) quattro S tronic | EA855evo/DNWA |
| Audi | RSQ3 | 2013, 2014 | RSQ3 | RSQ3-2.5 TFSI (310 Hp) quattro S tronic | CTSA |
| Audi | RSQ3 | 2016, 2017, 2018 | RSQ3 (facelift 2015) | RSQ3 (facelift 2015)-2.5 TFSI performance (367 Hp) quattro S tronic | CZGB |
| Audi | RSQ3 | 2015, 2016 | RSQ3 (facelift 2015) | RSQ3 (facelift 2015)-2.5 TFSI (340 Hp) quattro S tronic | CZGA |
| Cupra | Formentor | 2021, 2022, 2023 | Formentor | Formentor-VZ5 2.5 TSI (390 Hp) 4Drive DSG | DNWB |
Audi RS3
Years:
2015, 2016
Generations:
RS3 sportback (8VA)
Variant:
RS3 sportback (8VA)-2.5 TFSI (367 Hp) quattro S tronic
Engine Codes:
CZGB
Audi RS3
Years:
2024
Generations:
RS3 Sportback (8Y, facelift 2024)
Variant:
RS3 Sportback (8Y, facelift 2024)-2.5 TFSI (400 Hp) quattro S tronic
Engine Codes:
Audi RS3
Years:
2024
Generations:
RS3 Sedan (8Y, facelift 2024)
Variant:
RS3 Sedan (8Y, facelift 2024)-2.5 TFSI (400 Hp) quattro S tronic
Engine Codes:
Audi RS3
Years:
2021, 2022, 2023, 2024
Generations:
RS3 Sportback (8Y)
Variant:
RS3 Sportback (8Y)-2.5 TFSI (400 Hp) quattro S tronic
Engine Codes:
EA855evo/DNWC
Audi RS3
Years:
2021, 2022, 2023, 2024
Generations:
RS3 Sedan (8Y)
Variant:
RS3 Sedan (8Y)-2.5 TFSI (400 Hp) quattro S tronic
Engine Codes:
EA855evo/DNWC
Audi RS3
Years:
2017, 2018, 2019, 2020
Generations:
RS3 sportback (8VA, facelift 2017)
Variant:
RS3 sportback (8VA, facelift 2017)-2.5 TFSI (400 Hp) quattro S tronic
Engine Codes:
EA855evo/DAZA
Audi RS3
Years:
2017, 2018, 2019, 2020
Generations:
RS3 sedan (8V, facelift 2017)
Variant:
RS3 sedan (8V, facelift 2017)-2.5 TFSI (400 Hp) quattro S tronic
Engine Codes:
EA855evo/DAZA
Audi TT
Years:
2021, 2022
Generations:
TT RS Coupe (8S, facelift 2019)
Variant:
TT RS Coupe (8S, facelift 2019)-Heritage Edition 2.5 TFSI (394 Hp) quattro S tronic
Engine Codes:
EA855evo/DAZA
Audi TT
Years:
2020, 2021, 2022, 2023
Generations:
TT RS Coupe (8S, facelift 2019)
Variant:
TT RS Coupe (8S, facelift 2019)-2.5 TFSI (400 Hp) quattro S tronic
Engine Codes:
EA855evo/DNWA
Audi TT
Years:
2019, 2020
Generations:
TT RS Roadster (8S, facelift 2019)
Variant:
TT RS Roadster (8S, facelift 2019)-2.5 TFSI (400 Hp) quattro S tronic
Engine Codes:
EA855evo/DAZA
Audi TT
Years:
2020, 2021, 2022, 2023
Generations:
TT RS Roadster (8S, facelift 2019)
Variant:
TT RS Roadster (8S, facelift 2019)-2.5 TFSI (400 Hp) quattro S tronic
Engine Codes:
EA855evo/DNWA
Audi TT
Years:
2019, 2020
Generations:
TT RS Coupe (8S, facelift 2019)
Variant:
TT RS Coupe (8S, facelift 2019)-2.5 TFSI (400 Hp) quattro S tronic
Engine Codes:
EA855evo/DAZA
Audi TT
Years:
2016, 2017, 2018
Generations:
TT RS Roadster (8S)
Variant:
TT RS Roadster (8S)-2.5 TFSI (400 Hp) quattro S tronic
Engine Codes:
EA855evo/DAZA
Audi TT
Years:
2016, 2017, 2018
Generations:
TT RS Coupe (8S)
Variant:
TT RS Coupe (8S)-2.5 TFSI (400 Hp) quattro S tronic
Engine Codes:
EA855evo/DAZA
Audi RSQ3
Years:
2019
Generations:
RSQ3 (F3)
Variant:
RSQ3 (F3)-2.5 TFSI (400 Hp) quattro S tronic
Engine Codes:
EA855evo/DNWA
Audi RSQ3
Years:
2019
Generations:
RSQ3 Sportback
Variant:
RSQ3 Sportback-2.5 TFSI (400 Hp) quattro S tronic
Engine Codes:
EA855evo/DNWA
Audi RSQ3
Years:
2013, 2014
Generations:
RSQ3
Variant:
RSQ3-2.5 TFSI (310 Hp) quattro S tronic
Engine Codes:
CTSA
Audi RSQ3
Years:
2016, 2017, 2018
Generations:
RSQ3 (facelift 2015)
Variant:
RSQ3 (facelift 2015)-2.5 TFSI performance (367 Hp) quattro S tronic
Engine Codes:
CZGB
Audi RSQ3
Years:
2015, 2016
Generations:
RSQ3 (facelift 2015)
Variant:
RSQ3 (facelift 2015)-2.5 TFSI (340 Hp) quattro S tronic
Engine Codes:
CZGA
Cupra Formentor
Years:
2021, 2022, 2023
Generations:
Formentor
Variant:
Formentor-VZ5 2.5 TSI (390 Hp) 4Drive DSG
Engine Codes:
DNWB
